TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time

TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time

Dettagli:
Luogo di origine: Cina
Marca: SKYLIE
Certificazione: CE, Calibration Certificate, Rosh, CO...
Numero di modello: SL-P22
Termini di pagamento e spedizione:
Quantità di ordine minimo: 1
Imballaggi particolari: pacchetto di legno di legno esportato
Tempi di consegna: 15 giorni lavorativi
Termini di pagamento: L/C, D/P, D/A, T/T, Western Union, MoneyGram
Capacità di alimentazione: 20-30 /mese
Contatto
Descrizione di prodotto dettagliata
Campo di misura: (10 ~ 1000) mN Prova la velocità: 1.2 mm/s
Tempo di misurazione: 15 anni Risoluzione: 1mN
accuratezza: ± 1% Profondità di penetrazione della sonda: 8 + 0,5 mm
Larghezza ridotta della piattaforma campione: 5 mm, 6,35 mm, 10 mm, 20 mm Errore di parallelismo su entrambi i lati della fessura del tavolo campioni: ≤0.05mm
Alimentazione elettrica: CA 220 V ± 22 V, 50 Hz
Evidenziare:

10-1000mN Measuring Range Tissue Softness Tester

,

1.2mm/s Test Speed TAPPI T498 Test Machine

,

15s Measurement Time Softness Testing Equipment

TAPPI T498 Tissue Softness Test Machine
TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time 0 TAPPI T498 Tissue Softness Tester with 10-1000mN Measuring Range 1.2mm/s Test Speed and 15s Measurement Time 1
Product Overview
The Tissue Softness Tester is a precision instrument that simulates hand feel to measure material softness. Designed in compliance with GB8942 national standard for paper softness determination, it's ideal for testing medium and high-grade toilet paper, tobacco sheets, fabrics, and similar sheet materials.
Key Features
  • Microcomputer-controlled digital test system with touch screen interface
  • Bilingual (Chinese/English) operating system with intuitive controls
  • Advanced technology with reliable performance and easy operation
  • Ideal for paper manufacturing, scientific research, and quality inspection
Test Principle
The instrument measures softness by pressing a plate probe into the sample to a depth of approximately 8mm. The softness value (in millinewtons) represents the sum of the sample's maximum anti-bending force vector and the friction between sample and gap. Lower values indicate softer materials.
Compliance Standards
GB/T 8942 QB/T 1060 ASTM D2923 ASTM D6828-02 TAPPI T498 INDA IST 90.3 EDANA WSP 90.3
Technical Specifications
Parameter Specification
Measuring range (10 ~ 1000) mN
Test speed 1.2mm/s
Measurement time 15s
Resolution 1mN
Accuracy ±1%
Probe penetration depth 8 +0.5mm
Sample platform narrow width 5mm, 6.35mm, 10mm, 20mm
Parallelism error on both sides of the sample table slit ≤0.05mm
Display 5-inch touch screen with curve display (50,000 hour lifespan)
Power supply AC 220V ± 22V, 50Hz
Transport packaging Wooden outer box with internal buffer material
Product Demonstration
